The PLEX-SMD-5 IP66 series is a specially designed LED Strip that reduces heat and resistance, allowing for extra long runs up to 40M, incorporating SMD LED chip technology, utilising 70 LEDs per metre. Operating on 24V DC allows for less resistive heat and longer run lengths. Available in IP66 Strip with silicon coating for indoor or outdoor weatherproof installations. Available in 5W per metre, which provides a bright and desirable light output for your desired area. High CRI90 chips provide excellent colour rendering for a clean and minimalistic look.

The PLEX-SMD-5 IP66 series come with a choice of single colour 3000K Warm White, 4000K Neutral White and 5000K White for your residential or commercial linear lighting project applications. Ideal for extra long outdoor run lengths such as bars, restaurants, garden areas, under eave highlighting as well as commercial applications.

Please contact our friendly team for help with your next project.

Data Sheet

Finish:

• Clear Silicone Strip

For a clean, diffused finish, many people opt to install the LED strip inside extrusion.

Globe Type:

• Built in LED 70 chips per metre

Wattage:

• 5W per metre

Lumens:

• 525lm/m

Colour Temperature:

• Cool White - 4000K

Dimmable:

• Yes, with dimmable driver

Remote:

• Sold separately

Beam Angle:

• 120°

Voltage:

• 24v DC Constant Voltage (Driver and other control gear sold separately)

IP Rating:

• IP66

Dimensions:

• Length: 1000mm

Please Note: cuttable at 100mm intervals

• Width: 13mm

• Height: 5.4mm

Additional Information:

• Max Cut Length: 40,000mm

Warranty:

• 3 Year Warranty

• All LED strip must be installed on an aluminium heat sink, failure to do so WILL VOID WARRANTY.
